MitySOM-A5E System on ModuleProduction-ready System on Module based on Altera Agilex 5E FPGA with up to 656KLE fabric.

Product status: Prototypes Available



Overview

The MitySOM-A5E is a system on module featuring an Altera Agilex 5E SoC (System on a Chip) and includes up to 656KLE FPGA fabric, dual core Cortex-A55 + dual core Cortex-A76, on-board power supplies, and memory subsystems. The Altera Agilex 5 delivers 2.5x the performance at 50% less power consumption versus the Cyclone V SoC.

Prototypes of the MitySOM-A5E and the MitySBC-A5E are currently available. Contact Critical Link at info@criticallink.com to get more information.



Specifications

Altera Agilex 5E SoC

  • Agilex 5E-Series: 23mm x 23mm package
  • FPGA fabric 85KLE up to 656 KLE
  • Dual core Cortex-A55 + Dual core Cortex-A76
  • Optional transceivers

Memory

  • 8 GB LPDDR4
  • SD/eMMC
  • uSD
  • QSPI NOR for configuration

Power

  • 5-12Vdc Input, all supplies generated on board

Interfaces

  • MIPI (x4 lanes x 7)
  • UART
  • SPI
  • I2C
  • USB2
  • RGMII
  • Ethernet
  • Display Port
  • 48 LVDS pairs
  • GPIO

Applications

  • Artificial Intelligence
  • Video & Vision Analytics
  • Biometrics
  • Radios & Communications
  • Automated Test & Measurement
  • Robotics
  • Industry 4.0 / Industrial IOT
  • Medical Equipment & Imaging
  • Process Automation
  • Equipment / Condition Monitoring



Documentation



Block Diagram



Block diagram of the MitySOM-A5E, a system on module featuring the Altera Agilex 5E FPGA















Block diagram of the MitySOM-A5E, a system on module featuring the Altera Agilex 5E with optional transceivers















Mechanical

Dimensions Length Width
Inches 3.2 2.0
Millimeters 82.0 50.8



























Development Kit



Visit the MitySOM-A5E Development Kit product page to learn more

















Technical Support

Our customers benefit from engineering and applications support for the life of their product. This includes free, lifetime access to our technical support site, as well as access to application engineering resources and other services.

  • In the future, customers will be able to visit our MitySOM-A5E Wiki to access:
    • Linux OS and board support package details, including source code
    • Product change notices
    • Base board design guide
    • Development kit base board design files
    • Software guide to getting started, tool chain, tips and how-to’s
    • Hardware power draw, pin outs, shock and vibration, CAD files, mechanical drawings and 3D models
    • Frequently asked questions
  • Customers will also be able to visit our MitySOM-A5E Forum to access:
    • Software, Hardware, and FPGA forums
  • Altera Agilex 5E-series Documentation

Critical Link’s embedded design team also offers engineering services and other support options such as:

  • Schematic design review for customer designed carrier boards
  • Complete design review services
  • Software development services, including custom BSP development
  • Base board development services
  • Systems Engineering, Software, and Hardware Design to support your project anywhere in the product development lifecycle

Contact us for more information on these services.



Related Products



Purchase

The following table lists the standard configurations for Critical Link’s MitySOM-A5E Altera Agilex 5 based modules. For shipping status, availability, and lead time of these configurations please contact Critical Link at info@criticallink.com.



Orderable P/N FPGA KLE HPS / CPU Speed Grade No. XCVRs HPS RAM (32-bit) On-board Flash Operating Temperature Buy
A5ED-B4-61D-RC 85 800 MHz 4 2 GB 265 MBit 0C to +70C Buy
A5ED-B4-61D-RI 85 800 MHz 4 2 GB 265 MBit -40C to +85C Buy
A5ED-B5-61D-RC 138 800 MHz 4 2 GB 265 MBit 0C to +70C Buy
A5ED-B5-61D-RI 138 800 MHz 4 2 GB 265 MBit -40C to +85C Buy
A5ED-B9-61E-RC 656 800 MHz 12 4 GB 265 MBit 0C to +70C Buy
A5ED-B9-61E-RI 656 800 MHz 12 4 GB 265 MBit -40C to +85C Buy
A5ED-B9-61F-RC-X* 656 800 MHz 12 8 GB 265 MBit 0C to +70C Buy

*  -X suffix indicates preproduction silicon

Find your local sales contact or submit a request directly to Critical Link.
